26 Ton XP263 Hydraulic Tire Road Roller Engine Brand SHANGCHAI Warranty 1 Year

XP263 pneumatic tire roller is a large-tonnage pneumatic tire roller produced according to market requirements, which will take pneumatic tires as working device for compacting paved materials. The pneumatic tire roller is mainly applicable for compacting operation of asphalt pavement, foundation layer, secondary foundation layer, dam and flling engineering. It is an ideal set of compacting equipment for building high grade highway, airport, port, dam and industrial construction site.

Performance Characteristics:
1. SC7H180.2G3 electronic control diesel engine has the advantages of high reliability, fuel economy and low noise. Its emission should meet standard in national III stage.
2. Transmission system comprises torque converter, power shift transmission, drive axle, axle, chain and rear wheel. Adopt torque converter with continuously variable transmission as well as power shift transmission, and make roller have automatic adaptability, improving transmission stability in compaction, and guarantee the diesel engine to normally work under rated condition.
3. Dual-circuit brake technology has higher brake effect, fast response speed, short brake distance and higher reliability. Guarantee safety of the whole machine, and it is particularly applicable for working in mountainous area.
4. The machine uses the box type integral frame, each part of the body is designed with access hole and overturned cover board to facilitate maintenance and curing of each component.
5. Front four and rear five tires layout is adopted. All tires are installed with scrapers for cleaning adhesive materials on the tire reads. The grounding specific pressure can be adjusted in the range of 200kPa ~ 470kPa, good compaction uniformity.

6. Excellent performance
Adopting the pneumatic tyre to compact the layer will not damage the compacted materials. The compact performance can be improved by adding or reducing the counterweight and changing the inflation pressure of the tyres. Because of the kneading effect produced by the tyre’s elasticity, the material displacement will be produced in all directions, forming even dense surface without cracks, which can prolong the service life of the road.
Adopt the front wheels swing mechanism. When the machine works on rough road, the mechanism ensures the even ground pressure, which can make the materials be compacted evenly.
The optional international leading infrared tyre heating system realizes the no water sprinkling work of the compactor, and improves the density and service life of the road.
Product Paramenters
