    100 Ton 8 Axles Q345B 40ft Carbon Steel Flatbed Trailers

    Ask Lasest Price
    Brand Name : HARVEST
    Model Number : HRLMC950P30L
    Certification : CE/DOT/ADR
    Price : Negotiable
    Payment Terms : T/T
    Supply Ability : 1000 units/month
    Delivery Time : 15 days
    • Product Details
    • Company Profile

    100 Ton 8 Axles Q345B 40ft Carbon Steel Flatbed Trailers

    8 Axles 40ft Flatbed Trailers with Dolly 100 Ton Capacity for Mongolia Market

    Our trailers are novel in shape, unique in design, reasonable in structure, sturdy and durable. They are used to transport heavy-duty goods and containers which are with twist locks, and have been unanimously recognized and highly praised by customers.

    3 axles flatbed trailers with 2 axles dolly are very popular in Mongolia.
    We can produce the trailers according to your requirements such as 40ft or 45ft size, 8 or 12 twist locks, FUWA, BPW, or normal axles which can help you save cost, radial tube & tubeless tyres available for your option.

    Advantages

    1. The main parts of the trailer are made by advanced equipment, and the main beam is welded by an automatic submerged arc welding machine. All components are sandblasted to improve paint adhesion.

    2. The chassis is welded with the strong structure to improve cargo handling capacity and increase loaidng capacity.

    3. We have more than 9 years' experience of exporting trailers, so we are familiar with market of different countries.

    Technical Specification

    Loading capacity100 ton
    Overall Size28100x2500x1550mm

    Chassis (I beam)


    Top flange plateMaterial and thicknessQ345B 18mm
    Bottom flange plateMaterial and thicknessQ345B 20mm

    Middle flange plate

    MaterialQ345B
    Thickness12mm
    Height520mm

    Side beam height

    TypeU steel
    Height18# U steel

    Floor

    MaterialCarbon steel Q235
    Thickness3mm
    Fifth wheel3.5”

    Axle

    BrandFUWA
    Type16 ton
    Number4pcs
    RimType8.5
    Number32pcs

    Tire

    BrandTriangle brand
    Type12.00R20 tube tyres
    Number32pcs
    SuspensionMechanical suspension

    Spring leaf

    Leaf width120mm
    Leaf thickness16mm
    Layer/set12 Layer
    King pinTypeBolts type
    Diameter3.5 inch

    Brake system

    Air tank45L air tanks
    Brake chamber4 double spring brake chamber
    ABSWithout

    Landing gear

    BrandJOST E100
    TypeTwo speed 24t

    Accessories


    Spare tire carrier2sets
    LightLED light
    Voltage24v
    Receptacle7 ways(7wire harness)and quick change type
    Tool boxOne piece,1000x500x500mm
    PaintingPolyurethane paint&anti-rust primer & sand blasting
    Tools for trailerHead wrench ;spare wheel crank
