    175KW 220HP Planetary Gear Crawler Bulldozer Shantui Sd22 Hydraulic

    Ask Lasest Price
    Brand Name : Shantui
    Model Number : SD22
    Certification : CE/ISO9001
    Price : Negotiable
    Payment Terms : T/T
    Supply Ability : 1000 units/month
    Delivery Time : 15-20 days
    • Product Details
    • Company Profile

    175KW 220HP Planetary Gear Crawler Bulldozer Shantui Sd22 Hydraulic

    220HP Shantui Sd22 Bulldozer Optional ripper Cummins engine Excellent quality

    SD22 hydraulic bulldozer is a hydraulic transmission bulldozer developed by Shantui, and its technology has reached the domestic leading level. This product inherits Shantui's more than 30 years of bulldozer production experience, with excellent quality, stable and reliable performance. It is mainly suitable for the operations of pushing, excavating, backfilling earth and stone and other bulk materials on roads, railways, airports and other ground. It is an indispensable mechanical equipment for national defense projects, urban and rural roads and other construction and water conservancy construction.welcome to contact us get good price.

    ● Equipped with WP12/QSNT-C235 electronically controlled engine to meet the national phase III emission requirements for non-road machinery, with strong power, high efficiency and energy saving, and low maintenance costs;

    ●The torque reserve coefficient is large, and the rated power reaches 175kW;

    ●Using a radially sealed air intake system, effectively improving the service life of the engine.


    Technical Specifications
    EngineModel & typeCummins NT855-C280S10; In-line, water cooled 4-cycle,
    overhead valve direct injection, turbocharged diesel
    HorsepowerGross power: 175/235/1800 kW/HP/rpm //
    Net power: 162/220/1800 kW/HP/rpm
    Number of cylinders6—139.7 x 152.4 mm (bore x stroke)
    Piston displacement14.01 L
    Min. fuel consumption205 g/kW·h
    Maximum torque1030 N·m@1250rpm
    Power transmission systemTorque converter3-element, 1 stage, 1 phase
    TransmissionPlanetary gear, multi-disc clutch, power shift, forced lubrication
    Main driveSpiral bevel gear, splash lubrication,
    single-stage speed reduction
    Steering clutchWet, multi-disc, spring loaded, hydraulically separated,
    hydraulic control
    Steering brakeWet, floating band, foot brake with hydraulic booster
    Final drive2-stage speed reduction of spur gear, splash lubrication
    Travel speedGear1st2nd3rd
    Forward0~3.6 km/h0~6.5 km/h0~11.2 km/h
    Reverse0~4.3 km/h0~7.7 km/h0~13.2 km/h
    Undercarriage
    system
    TypeSwing type of sprayed beam,
    suspended structure of equalizer bar
    Carrier rollers2 each side
    Track rollers6 each side
    Track typeAssembled, single-grouser
    Width of track shoes560/610/660 mm
    Pitch216 mm
    Hydraulic
    System
    Maximum pressure14 MPa
    Pump typeGear pump
    Discharge262 L/min
    Bore of working cylinder × no.120 mm × 2
    BladeBlade TypeStraight-tiltAngleU-blade
    Dozing capacity6.4 m 34.7 m 37.5 m 3
    Efficiency
    (Theoretical value 40 m)
    330 m 3 /h245 m 3 /h391 m3/h
    Blade width3725 mm4365 mm3800 mm
    Blade height1315 mm1055 mm1343 mm
    Maximum drop below ground540 mm535 mm540 mm
    Lifting height of blade1210 mm1290 mm1210 mm
    Weight of blade2830 kg3254 kg3419 kg
    Riipper
    (Optional)
    Maximum digging
    depth of 3-shank ripper
    666 mm
    Maximum lift above ground555 mm
    Weight of 3-shank ripper2495 kg
    Maximum digging
    depth of single ripper
    695 mm
    Maximum lift above ground
    515 mm
    Weight of single ripper2453 kg
