1.5m3 Self Loading Mixer HK1.5 With Electronic Weighing System 76KW
Euro 2
Self-loading concrete mixer is a kind of concrete mixer that can
complete the whole process of loading, weighing, mixing,
transportation and unloading by itself, which is equivalent to a
small mobile concrete mixing station. The machine is easy to
operate and simple to use.
Accurate measurement: The self-loading mixer is equipped with an electronic weighing
system that accurately measures the weight of raw materials such as
sand, gravel and cement before they are loaded into the mixing
tank.
Real-time monitoring: The weight is displayed on the control panel, allowing the
operator to monitor and adjust the quantity to ensure the correct
mix ratio. This ensures the consistency and quality of the concrete
mix.
HK2.5 Self Loading Mixer Truck Standard Configuration
Profile seamless steel pipe integrated frame, rear wheel steering.
Geometric volume 2.2 square. Maximum output of 1.5 cubic meters,
65KW engine in the cloud, 265 split torque converter, forward and
forward hydraulic control hopper, reversing image, zero digital
display water meter, hydraulic pump water, 23.5-16 tires, 10T
hydraulic steering drive axle. Deluxe cab, waterproof cabling, high
and low speed fan, adjustable seat. 270° tank rotation unloading,
electronic weighing system, heating and cooling air conditioning.
Specification of 65KW Self Loading Mixer HK1.5
| Model | HK1.5 |
| Type | Integral frame chassis movable, self loading, mixing, transporting |
Function | Concrete, sand, fertilizer compound, wet or dry feed materias
mixing and discharging |
| Productivity | Batch≤15mins, 4 batchs/hour |
| Driving | 4 x 4 |
| Steering | Rear steering |
Engine | Yunnei engine: four-cylinder 2200rpm, 65kw |
| Speed | High speed: 30km/h; Low speed:4km/h |
Gear number | Three forwards, three backwards |
Fuel consumption | Idle state 1L-1.8L, working state 4L-6L. |
| Tire | 23.5-16 (Steel wire tyre) |
| Drum | Geometric volume 2.2 cubic meters, the best stirring 1.2-1..5 cubic
meters |
Spiral blade in tank | Double helix mixing, with the guide screw, so that the mixing
material more uniform.Turn the feed left, turn the discharge right |
Tilt of mixing tank | 16° |
Mixing tank 70°discharges | The tank rotates horizontally to 270 degrees.There is no dead Angle
for discharging around the vehicle |
| Tipping chute | Equipped with 2 chute for detachable to increase discharging length |
| Shovel | Shovel capacity: 0.35m³ |
Bucket discharge switch | Hydraulic gate, electric control |
| Operation handle | Electric control button four-way guide handle |
Moving hydraulic | Pump: Denghong |
Torque converter: HANK |
Work hydraulic | Pump/valve: Denghong |
Mixing system | Speed reducer: HANK |
Mixing motor: ZHENJIANG DALI |
| Drive axle | Liufeng |
Water supply | Hydraulic driving self-priming pumps |
High-pressure water pump wash | High-pressure water pump wash |
Weighing system | Electronic weighing system (language optional) |
| Voltage | Battery 24V-100A 2 pieces |
| Hydraulic oil box | Tankage110L, Summer: NO68 hydraulic oil, winter: NO46 hydraulic
oil, very cold zone: NO35 hydraulic oil |
Water tank capacity | 240L |
Diesel tank capacity | 110L |
Whole weight | Complete vehicle kerb mass 5600kg |
| Cab | Prevent falling objects cab |
| Adjustable steering wheel |
| Adjustable seat |
| Fire extinguisher |
| Astern image |
| Alarm lamp | Standard configuration |
| Radio | Standard configuration |
| A/C | Optional |
| Escape hammer | Standard configuration |
Astern sound prompt | Standard configuration |
Walking control mode | Standard: Configuration mechanical | Optional:Electric control |
1.5m3 Self Loading Mixer Arm With Hatch Bucket For Hot Sale
The loading arm of the self-loading concrete mixer with the
inclined automatic loading bucket ensures a smooth flow of material
into the drum, thereby minimizing leakage.
HK1.5 Self Loading Concrete Mixer Easy of Operation For Sale
Electric control button four-way pilot single joystick, a variety
of functions, hydraulic operation of the lever is easy to operate,
so that the driver work easier.
65KW Self Loading Mixer Truck Cabin With Ergonomic Design For Hot
Sale
The cabin is designed to enhance the efficiency of the operator and
allowing him to work for longer hours. The adjustable steering
wheel can help the driver find the most comfortable driving
position, thereby improving the safety and comfort of driving.
High Gradeability of Near Me Self Loading Concrete Mixer For Sale
The high gradeability is very effective on steeply sloping terrain.
HK1.5 has advanced technology for delivering concrete even at an
inclined position.
Maximum Output 1.5m3 Self Loading Mixer With Drum Swivel Wariant
Now gain an added advantage by giving your drum 270° rotary
discharge function for better discharge in all directions at your
work site.
